MACHINE OVERVIEW - EVOMAG28
The parts diagram can be downloaded from www.evolutionpowertools.com/downloads/parts
(4.3)
ADDITIONAL ACCESSORIES
In addition to the accessories supplied with
this machine the following accessories are
available from Evolution’s online shop at
www.evolutionpowertools.com or from your
local retailer.
(4.4)
Description Machine Part No.
3 piece Cutter Kit All _
6 piece Cutter Kit All _
Cyclone Cutters All _
Chuck & Key EVOMAG28 HTA153
Chuck Arbor EVOMAG75 HTA53
Chuck & Key EVOMAG75 HTA54
1” Countersink - 3 Flute, 82 Degrees, 3/4” Shank EVOMAG50 & 75 CS823F
1-1/2” Countersink- 3 Flute, 82 Degrees, 3/4” Shank EVOMAG50 & 75 CS823F-15
2” Countersink - 3 Flute, 82 Degrees, 3/4” Shank EVOMAG50 & 75 CS823F-2
Chuck Adaptor EVOMAG50 HTA46
Chuck & Key EVOMAG50 HTA51
1. Spindle Hub & Handles
2. Integrated Coolant System
3. Annular Cutter (Not included)
4. 3 Jaw Chuck
5. Arbor Support Bracket
6. Switch Panel
7. Magnetic Base
8. Carbon Brushes
Machines shown without guards
fitted for illustrative purposes only.
2
3
1
6
5
7
8
4
