12
www.evolutionpowertools.com
MACHINE OVERVIEW
MACHINE FITTED WITH
ANNULAR CUTTER
1. Magnet On/Off Switch
2. Motor On/Off Switch
3. Guard
4. Annular Cutter (Not included)
5. Secondary Slide Locking Lever
6. Safety Strap
7. Coolant Tank
8. Spindle Hub And Feed Handles
MACHINE FITTED WITH
3 JAW CHUCK
9. 3 Jaw Chuck
10. Drill Bit (Not included)
3
6
7
5
9
10
4
2 81
