SPECIFICATIONS EVOMAG42 S28MAG
MACHINE METRIC IMPERIAL METRIC IMPERIAL
Motor (UK/EU) 230V - 240V ~ 50Hz 1200W - - -
Motor (UK/EU) 220V - 240V ~ 50HzV - - 1200W -
Motor (UK) 110V ~ 50Hz 1200W - 1200W -
Motor (USA) 120V ~ 60Hz - 10A - 10A
Number Of Speeds 1 1 1 1
Speed (No Load) - 220-240V 450min
-1
450rpm 480min
-1
480rpm
Speed (No Load) - 110V & 120V 450min
-1
450rpm 450min
-1
450rpm
Insulation Class 1 1 1 1
Power Cord Length 2.5m 8’ 2” 2.5m 8’ 2”
Weight 12kg 26lb 12kg 26lb
CUTTER CAPACITIES
Maximum Annular Cutting Capacity 42mm 15/8” 28mm 11/8”
Maximum Cutting Depth 50mm 2” 50mm 2”
Cutter Shank 19mm 3/4” 19mm 3/4”
Standard Twist Drill Capacity 13mm 1/2” 13mm 1/2”
MAGNET
Magnetic Adhesion 1300kg f 2860lbs f 1300kg f 2860lbs f
Minimum Plate Thickness 10mm 3/8” 10mm 3/8”
DIMENSIONS
Magnet Dimension 40 x 90 x 180mm
1-5/8 x 3-1/2 x
7-1/8”
40 x 90 x 180mm
1-5/8 x 3-1/2 x
7-1/8”
Maximum Machine Height 654mm 25-3/4” 650mm 25-5/8”
Minimum Machine Height 420mm 16-1/2” 420mm 16-1/2”
Machine Width 222mm 8-3/4” 200mm 7-7/8 ”
NOISE & VIBRATION
Sound Pressure Level L
PA
89.40 dB(A) K=3 dB(A)
110V: 91 dB(A) K=3 dB(A)
220-240V:90.7 dB(A) K=3 dB(A)
Sound Power Level L
WA
102.4 dB(A) K=3 dB(A)
110V: 102 dB(A) K=3 dB(A)
220-240V:101.7 dB(A) K=3 dB(A)
Hand Arm Vibration 0.629m/s
2
K=1.5m/s
2
110V: 2.41m/s 2 K=1.5m/s 2
220-240V: 2.12 m/s 2 K=1.5m/s 2
MODEL NUMBERS
United Kingdom
230V: 095-0001
110V: 095-0002
230V: 090-0005
110V: 090-0006
United States 095-0003 090-0007
Europe 095-0004 090-0008
