10 www.ews-tools.de
4. COMMISSIONING AND OPERATION
3. PROPERTIES
■ Unpack the tool shuttle / tool carrier, check it for completeness and report any transport damage
immediately to EWS Weigele GmbH & Co. KG.
■ Place the tool carrier securely on a stable table top at least 50 mm thick.
■ To assemble/replace the TP tool palettes, a size 5 Allen key is required for each of the 4 pan head
screws (not included in the scope of delivery).
■ Only insert tool holders into the tool inserts provided.
■ Check for damage before each use.
■ If damaged, the tool shuttle / tool carrier must not be used.
■ Set up near the processing machine.
of the tool shuttle/tool carrier:
■ Provision and protected storage of tool holders.
■ Depending on the requirements, individual composition of the palettes with the same or different tool
inserts.
■ Thenumber of tool inserts on the tool palette varies according to the shank size of the tool holders.
■ Tool inserts are available for a wide range of tool holder interfaces.
■ Tool palettes fit tool shuttles and tool carriers and are interchangeable.
■ Ideal for multi-tasking machines, turning lathes or modular systems.
■ Tool-friendly plastic inserts.
■ One tool shuttle/tool carrier can be used for several processing machines.
■ Time saving with sister tools quickly to hand.
Only from the tool shuttle:
■ safe transport due to 4 lockable transport castors.
■ Ideal for transport between a central setting and measuring device and the
processing machine.
■ Mounting blocks and storage compartments can be integrated (to be ordered separately).
Only from the tool carrier:
■ table structure with 4 stable feet.
TIP
Tool palettes with inserts for the tool shuttle/tool carrier are available for many interfaces in the
EWS-ONLINE CATALOGUE. www.ews-tools.de/OnlineCatalogue (Search with item number: TP%)
or contact the EWS sales department. Other tool palettes can also be supplied on request.
Example order: TP-V5-20 Tool palette for Varia V5 with 20 tool inserts
