Dimensions (height x width x depth) in standard version:
TS-400: approx. 968 x 613 x 665 mm
TC-100: approx. 292 x 613 x 258 mm
TC-200: approx. 554 x 613 x 364 mm
Empty weight in standard equipment (depending on tool palette or storage tray):
TS-400: from 49 to 55 kg
TC-100: from 8.5 to 10 kg
TC-200: from 10 to 12 kg
Maximum total weight:
TS-400: 455 kg
TC-100: 110 kg
TC-200: 212 kg
Total maximum load capacity:
TS-400: 400 kg
TC-100: 100 kg
TC-200: 200 kg
Maximum load capacity per tool palette:
TS-400, TC-100 and TC-200: 100 kg
Maximum load capacity per tool insert:
20 kg
Maximum angle of inclination:
TS-400: 10°
TC-100: 0°
TC-200: 0°
Operating temperature:
5-40°C
8. TECHNICAL SPECIFICATIONS
NOTE
Observe centre of gravity / tipping safety. The weight of the loaded upper tool palette(s) must
always be less than or equal to the weight of the loaded lower tool palette.
