124505 7-3 REV A
Catcher Frame
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 781567 2 NT .500-13 NL G5
2 604887 2 CE .375 X 3.00 WITH BALE
3 121303 1 CATCHER FRAME
4 029629 4 CS .375-16 X .75 HX FLK
5 605662 2 TENSION ROD
6 016899 6 NT .375-16 HX FLK ZNYC
7 029751 2 CS .375-16 X 1.00 HX FLK
8 121489 2 WEIGHT PLATE
9 768523 2 FW .343 X .687 X .051/.080H
10 036236 2 CS .312-18 X 1.00 HX G5
11 025395 4 CB .375-16 X 1.00 G5 ZNY
12 767954 4 FW 0.379 X 0.813 X 0.063
13 054502 4 NT 0.375-16 HX G5
14 120864 1 LATCH SUPPORT
15 604475 1 BUNGEE LATCH
16 068551 1 NT .250-20 HX ZY NL
17 704916 1 CS .250-20 X 1.25 HX G5
18 768515 2 FW .281 X .625 X .051/.080H
