124505 7-5 REV A
Catcher Lid—552396
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 603398 6 RIVET
2 117501 1 CATCHER INLET
3 604394 1 INLET SEAL
4 603400 13 FW .188 X .50 X .060
5 552396 1 CATCHER LID (COMPLETE ASSEMBLY)
6 117678 1 VENT MOUNT BRACKET
7 117584 1 BAG DIVIDER
8 604805 7 BLIND RIVET
9 064329 3 CS .250-20 X .625 HX G5
10 768515 6 FW .281 X .625 X .051/.080 HD ZN/YL
11 118562 1 DEBRIS GUIDE
12 068551 3 NT .250-20 HX ZY NL
13 120884 1 STIFFENER PLATE
14 120882 1 HINGE BRACKET RS
15 120883 1 HINGE BRACKET LS
16 768523 8 FW .343 X .687 X .051/.080H
17 036236 4 CS .312-18 X 1.00 HX G5
18 034272 4 NT .312-18 HX G5 ZNYC
