124505 7-7 REV A
Catcher Chute & Blades
NOTES:
1. Torque to 118 ft-lbs.
INDEX NO. PART NO. QTY. DESCRIPTION
1 604387 1 UPPER CHUTE
2 068551 3 NT .250-20 HX ZY NL
3 768515 4 FW .281 X .625 X .066
4 604475 3 BUNGEE LATCH
5 606945 2 CB .250-20 X 1.50 FUL ZN
6 606932 1 CATCHER CHUTE
7 124495-3 1 CATCHER GUARD
8 704916 1 CS .250-20 X 1.25 HX G5
9 602416 1 BLADE, 18.50" CAT-F-CW (54" DECK)
796649 1 BLADE, 16.50"-CAT-F-CW (48" DECK)
