124505 7-9 REV A
Catcher Bag Assembly—552460
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 117393 1 BAG SUPPORT
2 117390 1 BAG CATCH
3 602827 1 CB .312-18 X 1.25 ZNYC
4 117401 1 CLAMP BRACKET
5 768523 1 FW .343 X .687 X .051/.080H
6 058776 1 NT .312-18 HX ZY NL
7 552460 1 CATCHER BAG ASSEMBLY (BAG INCL. ITEMS 1–6)
