Connection of 1 microphone and of 2 EX-200 in parallel mode
CONNECTIONS
Do not point the microphone to the loudspeaker
EXAMPLES
(Larsen effect)
EX-200A,EX-250A, EX-300A
EX-200A,EX-250A EX-200A,EX-250A EX-200A,EX-250A, EX-300A
Basic configuration
The master L/R outputs
Of the mixer are connected
To the XLR IN socket
Filtered or of the 2 EX-200 Main OUT L R
EX B 600A
not filtered
EX B 600A
Filtered
Or not filtered
Mixer Mixer
Subwoofer Subwoofer
Configuration of 2 EX-200 and subwoofers
powered through a filtered output Mixer
EX-200A,EX-250A, EX-300A
OUT OUT
IN IN
Main OUT L R
Configuration of multiple 2 EX-200
Through the XLR output socket
OUT in parallel with the XLR IN socket
Mixer
