exergear AchieveHRC - Attach Magazine Rack; Attach Seat and Seat Post

97
9
7. Attach magazine rack
1. Slide into the rack underneath the com-
puter as shown
8. Attach seat and seat post
1. Attach the towel rail and seat mount to
the bottom of the seat as shown - (nuts
and washers located in the back of seat)
2. Fix the seat to the top of the seat post,
using the spanner to tighten both sides
3. Slide the seat post into the seat post
mounting tube and secure in position
with the pull plunger
FIXINGS:FIXINGS:
x 1
Part
No.
24
x 1
Part
No.
12c
x 3
Part
No.
12d
12c
12d
24
