Exerpeutic ACTIVcycle - Parts List

7
PARTS LIST
No.
Description
Qty
No.
Description
Qty
1
Controller
1
17
Filter
1
2
Left Pedal
1
18
AC Power Cable
1
3
Right Pedal
1
19
Square Sensor
1
4
Main Frame
1
20
Magnet Ring
1
5
Left Crank
1
21
Phillips Screw M5x6
1
6
Right Crank
1
22
Phillips Screw M6x12
6
7
Crank Cap
2
23
Phillips Screw M5x10
2
8
Left Cover
1
24
Self-Tapping Screw ST2.9x6.0
2
9
Right Cover
1
25
Self-Tapping Screw ST2.9x6.0
6
10
End Cap
4
26
Self-Tapping Screw ST2.9x6.0
4
11
Magnet Bracket
1
27
Self-Tapping Screw ST4.2x15.0
4
12
Cover Cap
2
28
Self-Tapping Screw with Flat
Washer ST2.5x6.5
2
13
Console
1
29
Flat Washer Φ5.1*Φ10.3*T0.8
1
14
Magnet
1
30
Spring Washer Φ6.1*Φ9.3*T1.6
6
15
Motor
1
31
Inner Tooth
WasherΦ5.3*Φ10.0*0.6T
1
16
Power Control Board
1
32
Flange Bolt M8x20
2
