Figure5
Frontleftanti-scalpbracketshown
1.Type1hardware
2.Type2hardware
3.Type3hardware
4.Type4hardware
5.(Type1)3/8–16x4hexscrew
6.(Type2&3)3/8–24x2hexscrew—Torqueto50–55ft-lb
(68–75N-m)
7.(Type4)3/8whizlocknut—Torqueto30–35ft-lb
(41–47N-m)
8.Springdiscwasher(conetowardsbolthead)
9.(Type1)3/8whizlocknutandheavyatwasher—Torque
to40–45ft-lb(54–61N-m)
10.(Type2)3/8nylocnutandheavyatwasher—T orqueto
30–35ft-lb(41–47N-m)
11.(Type3)3/8angednylocnutwithoutwasher—Torque
to30–35ft-lb(41–47N-m)
12.(Type4)3/8nylocnut—T orqueto30–35ft-lb(41–47N-m).
ServicingtheBattery
WARNING
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
Important:Themachineisshippedwithalled
leadacidbattery.
1.Removethebatterycoverfrommachine.
DANGER
Chargingthebatterymayproduceexplosive
gasses.Batterygassescanexplodecausing
seriousinjury.
•Keepsparks,ames,orcigarettesawayfrom
battery.
•Ventilatewhenchargingorusingbatteryin
anenclosedspace.
•Makesureventingpathofbatteryisalways
openoncebatteryislledwithacid.
2.Checkthevoltageofthebatterywithadigital
voltmeter.Locatethevoltagereadingofthebattery
inthetablebelowandchargethebatteryforthe
recommendedtimeintervaltobringthechargeup
toafullchargeof12.6voltsorgreater.
Important:Makesurethenegativebattery
cablesaredisconnectedandthebatterycharger
usedforchargingthebatteryhasanoutputof
16voltsand7ampsorlesstoavoiddamaging
thebattery(seechartbelowforrecommended
chargersettings).
Voltage
Reading
Percent
Charge
Maximum
Charger
Settings
Charging
Interval
12.6or
greater
100%
16volts/7
amps
NoCharging
Required
12.4–12.675–100%
16volts/7
amps
30Minutes
12.2–12.450–75%
16volts/7
amps
1Hour
12.0–12.225–50%
14.4volts/4
amps
2Hours
11.7–12.00–25%
14.4volts/4
amps
3Hours
11.7orless
0%
14.4volts/2
amps
6Hoursor
More
4
