EXPERT GRILL Concord - Page 11

11
16
15
Hardware Required:
• (Hardware B) x8
• (Hardware C) x4
Installation:
• Lock Left Front Leg (Part #10)
and Left Rear Leg (Part #9).
• Use 8 screws (Hardware B) and
4 washers (Hardware C).
Note: The washers concave side
down when install.
Parts Required:
• Firebox Body (Part #1) x1
• Right Rear Leg (Part #16) x1
• Right Front Leg (Part #15) x1
Installation:
• Insert the Right Rear Leg (Part #16)
and Right Front Leg (Part #15) into
Firebox Body (Part #1).
