EXPERT GRILL Concord - Assembly Instructions; Base and Frame Assembly

10
10
9
Assembly Steps
10
9
Parts Required:
• Left Front Leg (Part #10) x1
• Left Rear Leg (Part #9) x1
• Locking Caster (Part #11) x2
Installation:
• Insert Locking Caster (Part
#11) stem into bottom of Left
Front Leg (Part #10). Press into
hole until click is felt. Ensure
caster is secure and cannot
easily back out.
• Repeat for Left Rear Leg (Part
#9).
Parts Required:
• Firebox Body (Part #1) x1
• Left Front Leg (Part #10) x1
• Left Rear Leg (Part #9) x1
Installation:
• Insert the Left Front Leg (Part
#10) and Left Rear Leg (Part #9)
into Firebox Body (Part #1).
