Extech Instruments 42545 User Manual

Model 42545 Version 1.1 12/ 04
3
Meter Description
1. Laser pointer beam
2. IR Sensor
3. Measurement Trigger
4. Battery Compartment
5. LCD Display
6. Push-buttons
7. Handle Grip
1
2
3
4
5
6
7

Extech Instruments 42545 Specifications

Infrared Thermometer Specifications

range	-58 to 1832°F (-50 to 1000°C)
resolution	0.1°C/F
accuracy	± (2% of reading + 9°F/4°C) <30°F (-1°C)
emissivity	Adjustable from 0.1 to 1.00 (0.95 default value)
field of view	D/S = Approx. 50:1 ratio
laser power	Less than 1mW (Class II)
spectral response	8 to 14 μm (wavelength)

General Specifications

display	4½ digit backlit LCD display with function indicators
display rate	1 second approx.
operating temperature	32°F to 122°F (0°C to 50°C)
operating humidity	Max. 90% RH
power supply	9V battery
automatic power off	Approx. 7 seconds after the trigger is released
weight	10.2 oz. / 290g
dimensions	3.9 x 2.2 x 9.0” (100 x 56 x 230mm)
