Page
6
F
F
i
i
g
g
u
u
r
r
e
e
1
1
:
:
I
I
n
n
s
s
t
t
a
a
l
l
l
l
i
i
n
n
g
g
t
t
h
h
e
e
B
B
a
a
t
t
t
t
e
e
r
r
y
y
C
C
a
a
r
r
t
t
r
r
i
i
d
d
g
g
e
e
1
1
.
.
2
2
.
.
2
2
C
C
h
h
a
a
r
r
g
g
i
i
n
n
g
g
t
t
h
h
e
e
B
B
a
a
t
t
t
t
e
e
r
r
y
y
Charge the battery by inserting the wall mounted charger line cord into the
printer jack. Then insert the charger plug into an appropriate wall socket.
The Yellow/Amber charging LED will illuminate indicating that the battery is
being charged
The battery will be fast charged and after about 180 minutes the LED will go
off
To remove the battery cartridge, open the battery door and tip the battery
out of the printer
.
Note: To ensure a full charge do not operate the printer while charging.
Note: The wall mounted charger is a Class II equipment (
)
. Multiple
plug configurations comply with most international standards.
S3750THS
Input Voltage/Current 100-240 VAC/0.5A
Input Frequency 47-63 Hz
Output Voltage/Current
(
)
10VDC/1.4A
Note: The wall mounted charger is not supplied with
plugs for use in Korea.
!
Do not use a charger not approved by Extech for use with the
S3750THS. Use of an unapproved charger could damage the battery
pack or the printer and will void the warranty.
