CFI EXTEL MULTI PRO 3 & CB BUS PRO 3 - 09/2016
GB1
SUMMARY
1 SAFETY INSTRUCTIONS. ............................................ p.1
2 DESCRIPTION. ............................................................... p.2
3 COMPONENTS ............................................................... p.2
a. Indoor station
b. Outdor station
4 INSTALLING ................................................................... p.2
a. Installing of the outdoor station
b. Mounting the handset
c. Installing the transformer
5 WIRING ....................................................................p.3
a. Connecting the interphone
b. Connection of an electric catch, lock and of a gate motor
c. Connecting an extra indoor station (option CB BUS PRO 3)
d. Power supply connection
e. 3- or 4-family mode activation
6 TECHNICAL SPECIFICATIONS ................................... p.4
a. Indoor unit
b. Power supply
c. Outdoor station
7 OPTIONS ..................................................................p.4
8 TECHNICAL ASSISTANCE - GUARANTEE.............p.5
9 SAFETY INSTRUCTIONS.........................................p.6
1. SAFETY INSTRUCTIONS
Important :
• Please read the user manual thoroughly before installing or using this product.
• If you install this product for other people, please give the manual or a copy to the end user
Warning :
• The different elements can only be dismantled by an authorised technician. .
Safety instructions :
• To safely use this system, it is essential the tters, users and technicians follow the safety procedures described
in this manual.
• Specic warnings and caution symbols are indicated on the elements if necessary.
