EXTERIOR MACHINE
CONTROL
PANEL
STRAP
CHANNEL
TABLE TOP
PACKAGE
STOP
FIXED
CASTER
SWIVEL
CASTER
FIGURE1. MAJOR COMPONENTS, EXTERIOR
ELECTRICAL
COMPONENTS
STRAPPING
HEAD
DISPENSER
BRAKE
ASSEMBLY
DISPENSER
FLANGE
FIGURE2. MAJOR COMPONENTS, FRONT VIEW
-2-
