EXTENDGROUP EKH-455 - REEL CARRIER GROUP PARTS LIST

PARTS LIST, FIGURE 4 REEL CARRIERGROUP
KE
Y
Q'T
Y
PART NO. DESCRIPTION
FPH-204-040
11 1 7-04000-110 Separator
12 1 7-04000-120 Film holder body
13 1 7-04000-130 Spinder
14 1 7-04000-140 Rubber roller
15 2 7-04000-150 Shaft
17 3 7-04000-170 Click pulley
18 1 7-04000-180
A
djusting bracket
19 3 7-04000-190 Scored pulley fastener
20 1 7-04000-200 Connector shaft
21 2 7-04000-210 Lock wimble
22 1 7-04000-220 Film shaft
23 1 7-04000-230 Conical spring
25 2 2201411055 Spring,1.4*11.4*55
26 2 7-04000-260 Holder guide support
28 2 7-04000-280 Slide
29 3 227A03528 Rubber washer, Ф28*3.55
30 6 200R06025 Star-type handle, M6*25
31 2 227BA-3008 Grip ball(Black)
100 4 200H05012 Truss head machine screw, M5*12
101 6 200H04015 Truss head machine screw, M4*15
102 2 200A05030 Socket head cap screw, M5*30
103 2 201A05 Hex nut, M5
104 4 200G06008 Socket head set screw, M6*8
105 2 210AF606ZZ Bearing F606ZZ
107 3 212AS20 Ring, S-20
110 1 212CR15 Snap pin-R15
16
