MACHINE ASSEMBLY
STAND (see also Fig.1)
---Secure the 4castors to the stand base
section using the nuts provided, and position
the BRAKED castors at the FRONT of the
stand
-Next assemble the UPRIGHT sections to
the base unit, Be sure to use the
STRENGTHENING WASHERS when fitting
the upright sections
--Next assemble the basketry bracket and
basketry
--The BASE section is a useful storage area
for spare film rolls
MACHINE BODY(see also Fig2)
--Put the machine on the stand (ensuring
that the adjustable leveling feet locate in the
cups on the UPRIGHT sections ).OR the
machine on your bench if no machine stand
has been purchased.
NOTE: do not hold it by the handle of the
hood or the film holder unit (it is advisable to
use two people for this operation)
-Slide the reel carrier assembly from the
back of machine forwards, into the twin
slides, until the carrier extends about 300mm
to the front of the machine body ,the reel
carrier will have to be “eased” past the stop at
the rear of slides, the travel of the reel
carrier is now limited front and rear
--Cut the adhesive tape holding the hood
closed ,and position the wire package tray
using the 2 sets of hoods at the chamber, and
fitting the 2thumb screws to match at the front
of the chamber.
--Ensure that nothing remains loose in the
base of the chamber-it could seriously
damage the fans
--The hood should remain in the OPEN
positions, if necessary adjust by means of the
torsion bar adjustment bolt on the back of the
machine
--Fit the roll of center-folded film centrally on
the film shaft and lock in position using the
cones and the Allen key provided, the folded
edge of the film is fitted to the rear of the
machine-open edge to the front.
--Pull the end of the film through the 2 rods
carrying the perforator wheels. Over the top
roller ,and around the film separation table.
