TECHNICAL FEATURES
11
Chapter 2
Pellet feeding
Automatic pellet ignition
Self-adjusting combustion system and automatic
cleaning by means of lambda probe
Automatic dispensing of the primary and secondary
air ow rate
Preparation for external storage silo
Cleaning device for the external ue gas pass
Draught for modulating intake with control via
encoder of the ue gas intake speed
Pellet insertion controlled by safety re-cut rotary
valve
Complete management via microprocessor
REFERENCE FITTINGS DIAMETER FITTINGS FUNCTION
T1 1” Heating ow
T2 1” Fitting blocked - do not use
T3 1” Fitting blocked - do not use
T4 1” Heating return
T5 = T6 3/4” D.S.A. Safety exchanger attachments
T7 1/2”
Safety heat exchanger probe sump
connection
T8 3/4” Boiler water drain
Rotary valve
re-cut
Brazier in
refractory material
Loading screw
for pellets
gure 2.2
gure 2.3
