Extreme Networks AP305C User Manual

Mode Data Rate Power (dBm)
MCS 8 -66
MCS 9 -64
MCS 10 -60
MCS 11
-57
Device Specifications
Chassis dimensions
:
AP305C
: 6.35” W x 5.20” H x 1.25” D (161.3 mm x132.1 mm x 31.8 mm)
AP305CX
: 6.35” W x 5.20” H x 1.25” D (161.3 mm x 132.1 mm x 31.8 mm)
Weight
:
AP305C: 2.61 lbs (1.18 kilograms)
AP305CX (without antennas): 2.82 lbs (1.28 kilograms)
Antennas
AP305CX
: 4 external omnidirectional 2.4/5 GHz dual band antennas
AP305C
: 4 internal omnidirectional 2.4/5 dual band antennas
One dual band antenna is shared between Wi-Fi and BLE
ETH0 Ethernet port
: autosensing 100/1000G BASE-T/TX Mbps, with IEEE 802.3af- or 802.3at-compliant PoE, and
requires Cat6 cable.
Antenna Gain
WiFi 2.4 GHz: 2.7 dBi gain max
WiFi 5 GHz: 4.4 dBi gain max
Power Specifications
PoE input voltage range: 37-57 V
RJ45 power input pins: Wires 4, 5, 7, 8 or 1, 2, 3, and 6
Power Consumption
AP305C
:
DC power: 18.72 W with USB, 15.72 W without USB
PoE: 21.78 W with USB, 18.78 W without USB
AP305CX
:
DC power: 18.72 W with USB, 15.72 W without USB
PoE: 20.79 W with USB, 17.79 W without USB
AP305C and AP305CX Hardware Guide
13

Extreme Networks AP305C Specifications

General

Model	AP305C
Category	Wireless Access Point
Frequency Bands	2.4 GHz and 5 GHz
Antenna	Internal
Power over Ethernet (PoE)	Yes
MIMO	2x2:2
Wi-Fi Standards	802.11a/b/g/n/ac
Ethernet Ports	1 x 10/100/1000Base-T Ethernet port
Form Factor	Ceiling mount, Wall mount
PoE Support	802.3af/at
Security Features	WPA3, WPA2, WPA
Operating Temperature	0°C to 50°C (32°F to +122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity Range Operating	5% to 95% non-condensing
