+/- 45 min.
6 montage kosmos
Now unscrew the leveling feet that are not touching the
ground surface from above with a at screwdriver and
further ensure that the whole is level.
3. Place the backrest between the two seat halves and six
M6x14 bolts and cap nuts. M6. Now tighten all the
bolts.
in case you bought a xed table, rst mount the
aluminium prole to the small seat frame and the
tabletop connection on top of it, with M6*30mm bolts.
2. Now connect the two halves of the seat to the small
seat frame using three bolts M6x80 and three M8 nuts.
Attention: do not tighten them yet. Do not tighten
them yet.
1. First mount the table leg to the small seat frame with 4
bolts M6x30. Now remove the transport screw.
2 people
screwdriver
ASSEMBLY KOSMOS
UTILITIES
