Extron DTP T UWP 4K D Series • Remote Control 17
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Select and view input
Select an input
X!
! In
X!
•All
]
Select input
X!
to transmit to the
connected receiver
Example:
1!
In01•All
]
View input selection
!
X!]
Signal status
Request all signal statuses
E
OLS
}
Sig
X(
•
X(
*
X(]
Example: Input 1 • Input 2 * Output
HDCP status
View the HDCP status of the HDMI
input
E
I
X!
HDCP
}
HdcpI
X1!]
View the output HDCP status
E
OHDCP
} X1@]
HDCP Authorized device
Set HDCP authorization for HDMI
input
E
E
X!
*
X(
HDCP
}
HdcpE
X!
*
X(]
View input HDCP authorization status
E
EHDCP
} X(
•
X(]
Video breakaway
Select program video input only
X!
% In
X!
• Vid
]
View currently selected video input
%
X!]
Analog audio mute
Mute or unmute analog audio
X(
Z Amt
X(]
Read analog audio mute
Z
X(]
Analog audio breakaway
Select program audio input only
X!
$ In
X!
• Aud
]
View currently selected audio input
$
X!]
NOTES:
X! = Input number
X@ = Auto switch mode
X( = Status
X1! = Input HDCP status
X1@ = Output HDCP status
1 through max number of outputs
0 = disabled (default)
1 = enabled (highest active input has priority)
2 = enabled (lowest active input has priority)
0 = off, disabled, or not detected
1 = on, enabled, or detected
0 = No source detected
1 = Source detected with HDCP
2 = Source detected without HDCP
0 = No sink detected
1 = Sink detected with HDCP support
2 = Sink detected without HDCP support
