Extron electronics DTP T UWP 4K 232 D - Page 25

Extron DTP T UWP 4K D Series • Remote Control 18
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Enable or Disable (mute) HDMI
output embedded audio
Enable HDMI audio mute
E
1AFMT
}
Afmt1
]
Enable HDMI audio mute
Disable HDMI audio mute
E
0AFMT
}
Afmt0
]
Disable HDMI audio mute (default)
View HDMI audio configuration
E
AFMT
} X(]
Audio routing selection
Set input audio format
(HDMI input only)
E
I1*
X1*
AFMT
}
AfmtI*
X1*]
Set input audio format
(VGA input only)
E
I2*
X1*
AFMT
}
AfmtI*
X1*]
View input audio format
E
I
X!
AFMT
} X1*]
Video output color bit depth
Set video color bit depth mode
E
V
X1%
BITD
}
BitdV
X1%]
View video color bit depth mode
E
VBITD
} X1%]
Device name
Set the device name
EX1#
CN
}
Ipn •
X1#]
Change the device name to
X1#
Set device name to factory default
E
• CN
}
Ipn • DTP-T-UWP-4K-xxx-D-
[COLOR]
]
Set device name to default
Example: DTP-T-UWP-4K-232-D-[COLOR]
View device name
E
CN
} X1#]
NOTES:
X! = Input number
X( = Status
X1# = Transmitter name
X1% = Video color bit depth mode
X1* = Input audio format
1 through max number of inputs
0 = off, disabled, or not detected
1 = on, enabled, or detected
A text string of up to 24 alphanumeric characters and minus sign or
hyphen (-). No blank or space characters are permitted as part of a
name. The first character must be a letter, and the last character must
not be a minus sign or hyphen (default is DTP-T-UWP-4K-232-D-
[COLOR] or DTP-T-UWP-4K-332-D-[COLOR]).
0 = auto (default, based on sink EDID)
1 = force 8-bit
HDMI: 0 = embedded digital audio, 1 = analog audio input, 2 = auto
select (embedded digital audio takes priority)
VGA: 0 = disable analog audio embedding, 1 = enable analog audio
embedding
