3.4 Technical data for base/charging station
Ambient temperature for
base station:
-20°C to +50°C
Bluetooth:
Bluetooth V4.0 EDR, Class 1
2.4…2.4835 GHZ (ISM band)
Terminal assignment
(Handheld scanner)
USB cable
RS232 cable
USB/D+ green
USB/D- white
GND black
+UB brown
RS232-TXD white
GND brown
+UB yellow
Nominal values of
hazardous area base
station:
• maximum input voltage
Ui
iSCAN211EXB
4,9 V
iSCAN211EXB3
5,5 V
• maximum input current
li
480 mA
• maximum input power
Pi
1.25 W
• maximum internal inductance
Li
negligible
• maximum internal capacitance
Ci
iSCAN211EXB
112.4 µF
iSCAN211EXB3
190.3 µF
If using a power supply other than iSCANPSx:
• maximum input voltage
Ui
5.6 V
• maximum input current
li
480 mA
• maximum input power
Pi
1.25 W
• maximum internal inductance
Li
negligible
• maximum internal capacitance
Ci
46 µF
Note: The input voltage of the Bluetooth base station itself is reduced by the
associated connection cable ISCAN2XXCAB7 or 8 to 4.9V.
Nominal values of safe
area base station:
• operating voltage
U
5 V ±10%
• power requirement
I
85 mA in standby mode
