6. DC IN – Connect to 5V DC power adapter.
7. AV IN – Connect to composite video source such as VHS or Camcorder by the
included composite video adapter cable or/and the included 3RCA adapter.
Yellow=video, white=audio left channel, red=audio right channel.
Please use the included cable connect to video source device if the device includes
the direct RCA YELLOW and WHITE/RED female connectors. Sometimes maybe
device only with YELLOW and WHITE connectors, so you do not need to connect the
RED connector. Please use the included cable and adapter connect to video source
device if the device also includes the dedicated video output cable.
8. HDMI IN – Connect to HDMI OUTPUT of video source such as game console or
set-top box.
9. HDMI OUT – Connect to TV or monitor to display vide.
Note: Please do not connect HDMI input and Composite video input at the same time.
Start Work
Record Video
You will preview the video on TV or monitor when all connections are ready, press REC
button to record video, and RED led will light, it means it is recording. Press REC button
again to stop recording, RED led flashes few seconds then off, it means recorded video
has been saved in USB flash drive well.
Note: ezcap288 HD Video Capture only support HDMI PCM audio. Please set PCM
