Ezgo EXPRESS L4 - Page 35

Page C-3
Repair and Service Manual
B
B
BODY
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 3 Body Components Continued (Express L4 & Express S4)
Box Cooler and Bracket
Box Cooler
Floor Mat
Fender Liner
Seat Support
Battery Tray
Splash Panel
Frame
