Page C-4
Repair and Service Manual
B
BODY
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 4 Body Components Continued (Terrian 250, 500 & 1000)
Side Panel
Floor Mat
Rocker Panel
Battery Tray
Splash Panel
Seat Frame (For TERRIAN 500 AND 1000)
Seat Wrap W/Louvers
(For TERRIAN 250)
Floor Mount Gun Holder
Ashtray
