Page C-5
Repair and Service Manual
B
B
BODY
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 5 Rear Body Components
Rear Fender
Notched Rear Bumber
Rear Panel
TERRIAN 250, 500 & 1000
EXPRESS L4 & EXPRESS S4
Seat Hinge Plate
Seat Hinge Plate
Access Panel
