Ezgo EXPRESS L4 - Page 38

Page C-6
Repair and Service Manual
B
BODY
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 6 Seating (Express L4 & Express S4)
Front of Vehicle
Top of Vehicle
Seat Back Support
Seat Back Support
Seat Back Support
Flip Flop Seat Bottom Assembly
Seat Back Assembly
Hip Restraint
Seat Bottom Assembly
Footrest Handle
Handrail
Footrest Weldment
Seat Frame
Weldment
