Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 7 Seating (Terrian 250, 500 & 1000)
Seat Back Assembly
Seat Bottom Assembly
Seat Back Support Bracket
Seat Back Support Bracket
Seat Back Support
Access Cover
Hip Restraint
TERRAIN 250 & 500
TERRAIN 1000
