Page L-6
Repair and Service Manual
B
ELECTRICAL SYSTEM
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 6 Horn
Fig. 7 Turn Signal & Hour Meter
Front of Vehicle
BLK
YEL
H
O
R
N
Floorboard
Floormat
TURN SIGNAL
HOUR METER
HOUR METER
Solenoid
BLK
YEL
(+)
(-)
