Page E-1
Repair and Service Manual
B
B
FRONT SUSPENSION AND STEERING
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 1 Axle Mounted Steering and Front Suspension
Front of Vehicle
EXPRESS L6
King Pin
Tube
Thrust
Washer
Spindle &
King Pin
Bushing
Part of
Frame
Front Axle
Intermediate
Shaft with
U-Joints
Rack Extension
Rack Ball Joint
Wave Washer
Bearing
Outer Snap Ring
Inner Snap Ring
Spacer
Rack & Pinion
Unit
