MAINTENANCE
13
Run/Tow Switch Operation (P/N 679115)
Located on the run/tow switch.
Battery Warning (P/N 655748)
Located on the battery cover.
Rear Handhold Warning Label (P/N 697425)
DO NOT alter or tamper with this unit. Unauthorized modifications
can result in SERIOUS INJURY or damage to the vehicle and will
void the warranty.
WAIT 30 seconds after reconnecting batteries BEFORE moving the
RUN-TOW switch to the RUN position.
TOWING - Always select
‘TOW’ position before towing
679115
To disable electrical system, turn key switch to ‘OFF’ and set the
RUN-TOW switch to TOW. Disconnect the battery cables.
ALWAYS set the RUN-TOW switch to TOW/STORAGE
before disconnecting or connecting battery wires.
ELECTRICAL ARC or BATTERY EXPLOSION can
occur if the switch is NOT set to TOW/STORAGE.
RUN
TOW
STORAGE
FAILURE TO FOLLOW THESE INSTRUCTIONS
MAY RESULT IN SEVERE PERSONAL INJURY.
RECYCLE
RETURN
Li-Ion
Service, removal or installation of battery pack must be performed
by authorized personnel only.
Charge with an OEM approved Lithium-Ion battery charger only.
Do not store or operate at temperatures below -4°F (-20°C).
Do not expose to temperatures above 140°F (60°C).
No user serviceable parts.
655748
MAX
14
o
/ 25%
MAX 300 lb.
136 kg
MAX
4 in.
10 cm
697425
