Ezgo SHUTTLE 6 Service Manual

INDEX-3
Service Parts Manual
INDEX OF MAJOR COMPONENTS
P
PEDAL BOX ASSEMBLY................................................... A-3
PEDAL BOX ASSEMBLY, PDS MODEL ONLY................. A-3
PINION SEAL..................................................................... H-5
PUSH ROD ASSEMBLY.................................................... D-5
R
RACK AND PINION UNIT................................................... H-4
RACK BALL JOINT............................................................. H-5
RACK BOOT....................................................................... H-5
REAR AXLE AND BRAKE ASSEMBLY.............................. K-2
REAR AXLE AND BRAKE ASSEMBLY, PDS .................... K-2
REAR BODY ASSEMBLY.................................................. C-9
REVERSE WARNING BUZZER ......................................... E-3
S
SEAT ASSEMBLY............................................................. M-7
SEAT BACK....................................................................... M-6
SEAT BACK ASSEMBLY .................................................. M-5
SEAT BOTTOM................................................................. M-6
SEAT BOTTOM (SHUTTLE) ............................................. M-6
SEAT BOTTOM (TE5)....................................................... M-6
SEAT FRAME..................................................................... C-8
SEAT POD......................................................................... M-5
SHIFT BRACKET AND SWITCH........................................ D-7
SHOCK ABSORBER .................................................. H-4, L-2
SHOCK ABSORBER BOOT .............................................. H-4
SPINDLE............................................................................ H-3
STATE OF CHARGE METER............................................. F-8
STEERING COLUMN ........................................................ H-5
STEERING SHAFT............................................................ H-5
STEERING WHEEL........................................................... H-6
SUN TOP KIT (SHUTTLE)................................................. N-4
SUN TOP KIT (TE5)........................................................... N-5
T
TAILLIGHT ASSEMBLY ..................................................... F-9
TIE ROD ............................................................................. H-7
TIRE AND WHEEL, 18.5 X 8.5 - 8, 4 PLY RATING ........... P-2
TIRE AND WHEEL, 18.5 X 8.5 - 8, 6 PLY RATING............ P-2
TURN SIGNAL.................................................................... F-9
W
WINDSHIELD KIT, FOLD DOWN....................................... N-4
WINDSHIELD KIT, FULL.................................................... N-4
WINDSHIELD KIT, REAR.................................................. N-4
BY PART NUMBER
17421-G1 IGNITION SWITCH KIT..................................... F-8
17867-G1 TURN SIGNAL (WITH MOUNTING HARDWARE)...
F-9
17953-G2 BRAKE DRUM................................................... D-7
22260-G2 TAILLIGHT ASSEMBLY .................................... F-9
22674-G1 FUSE BLOCK.................................................... F-8
27772-G11 TIRE AND WHEEL, 18.5 X 8.5 - 8, 4 PLY RATING
P-2
28066-G02 MASTER CYLINDER REPAIR KIT.................. D-5
28363-G01 HORN SWITCH............................................... F-9
28435-G01 48V LESTER BATTERY CHARGER WITH SWIT-
CHABLE INPUT.................................................................. B-2
28435-G03 48V LESTER BATTERY CHARGER............... B-2
28435-G05 48V LESTER BATTERY CHARGER CE AP-
PROVED............................................................................. B-2
28435-G07 48V LESTER BATTERY CHARGER............... B-4
30295-G8 LINKAGE ROD ASSEMBLY ............................. D-4
30298-G2 PUSH ROD ASSEMBLY................................... D-5
32028-G2 TIRE AND WHEEL, 18.5 X 8.5 - 8, 6 PLY RATING.
P-2
33636-G03 STATE OF CHARGE METER.......................... F-8
33725-G01 BRAKE ASSEMBLY (PASSENGER SIDE) .... D-6
33725-G02 BRAKE ASSEMBLY (DRIVER SIDE) ............. D-6
48V LESTER BATTERY CHARGER .......................... B-2, B-4
48V LESTER BATTERY CHARGER CE APPROVED ....... B-2
48V LESTER BATTERY CHARGER WITH SWITCHABLE IN-
PUT..................................................................................... B-2
70046-G01 BATTERY RACK............................................. C-8
70361-G02 FOOT REST ASSEMBLY ............................. C-12
70441-G01 SEAT FRAME ................................................. C-8
70469-G01 SHOCK ABSORBER ....................................... L-2
70597-G02 LEAF SPRING ................................................ H-4
