Ezgo SHUTTLE 6 Service Manual

INDEX-4
INDEX OF MAJOR COMPONENTS
Service Parts Manual
70643-G03 MASTER CYLINDER SERVICE KIT............... D-5
70664-G02 LEAF SPRING (HEAVY DUTY)....................... H-4
70830-G01 DIRECTION SELECTOR ASSEMBLY............ E-2
70835-G** SEAT BOTTOM (TE5)...................................... M-6
70836-G00* SEAT POD..................................................... M-5
70853-G** SEAT BOTTOM (SHUTTLE) ............................ M-6
70866-G01 SHIFT BRACKET AND SWITCH..................... D-7
70886-G01 BRAKE PEDAL................................................ D-4
70928-G01 SHOCK ABSORBER....................................... H-4
70963-G01 FRONT AXLE.................................................. H-3
70964-G01 RACK AND PINION UNIT (COMPLETE)........ H-4
71051-G** COWL............................................................... C-8
71151-G01 INSTRUMENT PANEL ASSEMBLY................ C-7
71332-G3** REAR BODY ASSEMBLY (WITH TAILLIGHTS)...
C-9
71611-G** SEAT BOTTOM................................................ M-6
71646-G01 HAND HOLD KIT............................................. M-6
71751-G** SEAT BACK...................................................... M-6
71751-G** SEAT BACK ASSEMBLY ................................. M-5
71912-G6** REAR BODY ASSEMBLY (W/OUT TAILLIGHTS)
C-9
73068-G05 ELECTRONIC SPEED CONTROL ASSEMBLY G-
2
73124-G02 MOTOR, FLEET SPEED, NON-VENTED........ J-2
73290-G02 REVERSE WARNING BUZZER...................... E-3
73291-G04 MOTOR (SEPARATELY EXCITED) (PDS)...... J-2
73311-G0* CHARGER HARNESS / RECEPTACLE.......... F-7
73333-G07 PEDAL BOX ASSEMBLY, PDS MODEL......... A-3
73333-G08 PEDAL BOX ASSEMBLY................................ A-3
73348-G01 ELECTRONIC SPEED CONTROL ASSEMBLY G-
4
73504-G02 REAR AXLE AND BRAKE ASSEMBLY .......... K-2
73504-G03 REAR AXLE AND BRAKE ASSEMBLY, PDS. K-2
74001-G01 HEADLIGHT AND TURN SIGNAL LIGHT BAR F-9
74080-G01 CARGO DECK............................................... C-11
74131-G** SEAT ASSEMBLY............................................ M-7
74207-G01 LEAF SPRING.................................................. L-2
75113-G06 HOUR METER KIT........................................ F-10
75282-G0* SUN TOP KIT (SHUTTLE)............................... N-4
75485-G01 SUN TOP KIT (TE5)........................................ N-5
75534-G01 WINDSHIELD KIT, FOLD DOWN.................... N-4
75535-G01 WINDSHIELD KIT, REAR................................ N-4
75536-G01 WINDSHIELD KIT, FULL................................. N-4
