Ezgo SHUTTLE 6 - Page 39

Page D-7
Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
91 13464-G1 CLEVIS PIN RETAINER......................................................................... 1
92 22604-G1 STRAIGHT LEVER ................................................................................ 2
93
94 13468-G1 CLIP .................................................................................................................... 2
95 21559-G1 WIPER SEAL ...................................................................................................... 1
96 33662-G01 STUD, 5/16 - 24 X 1 5/8" LG............................................................................... 4
97 21562-G1 NUT, 5/16 - 24 ..................................................................................................... 4
98
99 XXXXX-XX AXLE SHAFT (DRIVER SIDE) (SEE REAR AXLE SECTION FOR P/N)............ 1
100 XXXXX-XX AXLE SHAFT (PASSENGER SIDE) (SEE REAR AXLE SECTION FOR P/N)... 1
101
102 XXXXX-XX BEARING RETAINER RING (SEE REAR AXLE SECTION FOR P/N)............... 1
103 XXXXX-XX WHEEL BEARING (SEE REAR AXLE SECTION FOR P/N) .............................. 1
104 XXXXX-XX INNER OIL SEAL (SEE REAR AXLE SECTION FOR P/N)................................ 1
105
106 17953-G2 BRAKE DRUM .................................................................................................... 2
107
108
109 70866-G01 SHIFT BRACKET AND SWITCH (INCLUDES ITEMS 110 - 116)....................... 1
110 70821-G01 BRACKET..................................................................................................... 1
111 70889-G01 LIMIT SWITCH.............................................................................................. 1
112 00645-G2 SCREW, #6 - 32 X 1 1/4" LG ........................................................................ 2
113 00559-G3 WASHER, #6 ................................................................................................ 2
114 00565-G3 LOCK WASHER, #6 ..................................................................................... 2
115 00525-G5 NUT, #6 - 32.................................................................................................. 2
116 12914-G1 FASTON TAB, 9/32" X 11/32" ....................................................................... 2
117
118 75791-G02 BRAKE LEVER WITH CABLE ............................................................................ 1
119 70926-G01 PULLY BRACKET ............................................................................................... 2
120 70841-G01 PULLY, 2" ........................................................................................................... 1
BRAKES - HYDRAULIC
