Ezgo SHUTTLE 6 - Page 77

Page M-5
Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 70836-G00* SEAT POD .......................................................................................................... 1
2 71316-G01 PLUG, 1 1/8"........................................................................................................ 1
3 71055-G01 RIVET, 3/16" X 1" LG .......................................................................................... 3
4 71599-G01 VENT PLUG........................................................................................................ 4
5 32805-G6 TRIM, BLACK...................................................................................................... 1
6 27731-G01 ASHTRAY............................................................................................................ 1
7
8 00439-G8 BOLT, 5/16 - 18 X 2" LG...................................................................................... 3
9 00675-G1 WASHER, 1 1/4" X 3/8"....................................................................................... 3
10 71883-G01 RUBBER WASHER, 5/8" .................................................................................... 3
11 23726-G9 SPACER, 3/4"...................................................................................................... 3
12 11098-G6 LOCK NUT, 5/16 - 18 .......................................................................................... 3
13
14 70820-G01 SEAT BACK SUPPORT ...................................................................................... 1
15 00976-G06 SCREW, 5/16 - 18 X 3/4" LG............................................................................... 2
16 11098-G6 LOCK NUT, 5/16 - 18 .......................................................................................... 2
17 00427-G8 BOLT, 3/8 - 16 X 2" LG........................................................................................ 2
18 00675-G1 WASHER, 1 1/4" X 3/8"....................................................................................... 2
19 23726-G4 SPACER, 5/16".................................................................................................... 2
20 15717-G5 ACORN NUT, 3/8 - 16 ......................................................................................... 2
21
22 71751-G** SEAT BACK ASSEMBLY .................................................................................... 1
23 71632-G01 HAND GRIP ........................................................................................................ 1
24 71204-G02 BOLT, 1/4 - 20 X 2" LG........................................................................................ 4
25
26 70845-G01 CONSOLE COVER (WITHOUT DIRECTION SELECTOR)................................ 1
27 70845-G02 CONSOLE COVER (WITH DIRECTION SELECTOR) ....................................... 1
28 70846-G01 SEAL (DIRECTION SELECTOR)........................................................................ 1
29 70847-G01 SEAL (BRAKE LEVER)....................................................................................... 1
30
SEATING
