Ezviz C3N Quick Start Guide

5
2 Connect to the Internet
• Wireless Connection: Connect the camera to Wi-Fi. Refer to Option 1.
• Wired Connection: Connect the camera to a router. Refer to Option 2.
Option 1: Use the EZVIZ app to congure Wi-Fi.
Steps:
1. Log in to your account using the EZVIZ app.
2. On the Home screen, tap “+” on the upper-right corner to go to the
Scan QR Code interface.
3. Scan the QR code on the Quick Start Guide cover or on the body of
the camera.
4. Follow the EZVIZ app wizard to nish Wi-Fi conguration.
Please choose to connect your camera to the Wi-Fi to which your
mobile phone has connected.
Hold the reset button for 5s to restart and set all parameters to
default.
Hold the reset button for 5s in any of the following cases:
• The camera fails to connect to your Wi-Fi network.
• You want to change to another Wi-Fi network.

Ezviz C3N Specifications

General

Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67
Sensor type	CMOS
Progressive scan	Yes
Number of sensors	1
Optical sensor size	1/2.7 \
Fixed focal length	2.8 mm
Maximum aperture number	2
Camera pan control	No
Minimum illumination	- lx
Type	IP security camera
Antenna type	External
Certification	CE / WEEE / REACH / ROSH / FCC / UL
Placement supported	Outdoor
Connectivity technology	Wired & Wireless
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet interface type	Fast Ethernet
Supported network protocols	EZVIZ cloud proprietary protocol
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
DC output current	1 A
DC output voltage	12
Power source type	DC
Power consumption (max)	7 W
LED type	IR
Night vision distance	30 m
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Master (outer) case width	500 mm
Master (outer) case height	255 mm
Master (outer) case length	541 mm
Master (outer) case weight	17025 g
Harmonized System (HS) code	85258900
Quantity per master (outer) case	16 pc(s)

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Weight	422 g
Package depth	100 mm
Package width	227 mm
Package height	92 mm
