Ezviz C4W User Manual

4
Setup
Step 1 Power-on
Plug the power cable into the camera and to the power adapter and then into a
power outlet, as shown in the figure below.
Power Outlet
Power Cable
Step 2 Camera Setup
1. Create a user account
- Connect your mobile phone to Wi-Fi.
- Download and install the EZVIZ app by searching “EZVIZ” in App Store or
Google Play
TM
.
- Launch the app and register for an EZVIZ user account following the start-
up wizard.
2. Add a camera to EZVIZ
- Log in the EZVIZ app.
- From the EZVIZ app Home screen, tap “+” on the upper-right hand corner to
go to the scan QR code interface.

Ezviz C4W Specifications

General

Type	IP security camera
Certification	UL / FCC / CE / WEEE / REACH
Day/night mode	Yes
Placement supported	Outdoor
Connectivity technology	Wireless
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet interface type	Fast Ethernet
Supported network protocols	Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Ethernet LAN (RJ-45) ports	1
Form factor	Dome
Mounting type	Ceiling
Product color	White
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67
Camera pan control	-
Minimum illumination	- lx
DC output current	1 A
DC output voltage	12
Power consumption (max)	6 W
Sensor type	CMOS
Optical sensor size	1/2.7 \
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Fixed focal length	2.8 mm
LED type	IR
Night vision distance	30 m
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, H.265
Noise reduction technology	3D noise reduction
Sustainability certificates	RoHS
Audio system	2-way

Weight and Dimensions

Height	95 mm
Weight	330 g
Diameter	105 mm
Package depth	145 mm
Package width	147 mm
Package height	173 mm
