Ezviz C6CN Manual

6
2
Install the Base
The camera can be placed horizontally or mounted on the ceiling. Here we
take ceiling mounting as an example.
• Make sure the ceiling is strong enough to withstand three times the
weight of the camera.
• Avoid positioning the camera in an area that gets a lot of light shining
directly into the camera lens.
- Place the drill template onto the surface you have chosen to mount the
camera.
- (For cement wall/ceiling only) Drill screw holes according to the template,
and insert three anchors.
- Use three metal screws to x the camera base according to the template.
Drill Template
Anchors
Metal Screws
Please tear up the drill template after installing the base if needed.

Ezviz C6CN Specifications

General

Type	IP security camera
Antenna type	Internal
Auto-tracking	Yes
Operating frequency	2.4 - 2.4835 MHz
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Spherical
Mounting type	Ceiling/Wall/Desk
Product color	Black, White
Tilt angle range	-15 - 105 °
Minimum illumination	- lx
Adjustment shutter speed	Auto
Sensor type	CMOS
Number of sensors	-
Optical sensor size	1/2.9 \
Digital zoom	8 x
Lens diameter	4 mm
LED type	IR
Night vision distance	10 m
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Wi-Fi standards	Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	72.2 Mbit/s
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Power source type	USB
Power consumption (max)	5 W

Weight and Dimensions

Width	87.7 mm
Height	112.7 mm
Weight	260 g
Package width	103 mm
Package height	188 mm
