General| Number of cameras | 1 |
|---|---|
| AC adapter included | Yes |
| Form factor | Spherical |
| Mounting type | Ceiling/wall |
| Product color | White |
| Sensor type | CMOS |
| Number of sensors | 2 |
| Optical sensor size | 1/2.7 \ |
| Digital zoom | 8 x |
| Pan range | 0 - 340 ° |
| Tilt angle range | 0 - 80 ° |
| Minimum illumination | 0 lx |
| Adjustment shutter speed | Auto |
| LED type | IR |
| Night vision distance | 30 m |
| Number of illumination LEDs | 4 |
| Lens mount interface | M12 |
| Sustainability certificates | CE, REACH, RoHS, WEEE |
| Type | IP security camera |
| Certification | UL, FCC, CE, WEEE, REACH, RoHS |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired & Wireless |
| Total megapixels | - MP |
| Maximum resolution | 1920 x 1080 pixels |
| Video compression formats | H.264, H.265 |
| Noise reduction technology | 3D noise reduction |
| Bluetooth | No |
| Frequency band | 2.4 - 2.4835 GHz |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Streaming method | Multicast |
| Channel bandwidth | 20 MHz |
| Wi-Fi data rate (max) | 72 Mbit/s |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | EZVIZ Cloud Proprietary Protocol |
| Security algorithms | 64-bit WEP, 128-bit WEP, TLS, WPA, WPA2, WPA2-PSK |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| DC output current | 1 A |
| DC output voltage | 12 |
| Power source type | DC |
| Power consumption (typical) | 12 W |
| Audio system | 2-way |
Weight and Dimensions| Depth | 164 mm |
|---|---|
| Width | 116 mm |
| Height | 154 mm |
| Weight | 578 g |
| Cable length | 1.5 m |
| Package depth | 205 mm |
| Package width | 185 mm |
| Package height | 197 mm |
| Package weight | 938 g |
