Ezviz C8W User Manual

2
Overview
1� Package Contents
Camera
Drilling Template Waterproof Kit Screw Kit
Power Adapter Regulatory Information Quick Start Guide
The power adapter's appearance is subject to the one you have bought.
2� Basics
Ethernet Port
Power Port
Antenna
MIC
Lens
Antenna
LED Indicator
Spotlight

Ezviz C8W Specifications

General

Number of lenses	1
Fixed focal length	4 mm
Maximum aperture number	1.6
LED type	IR
Certification	UL / FCC / CE / WEEE / REACH / RoHS / UKCA
DC output current	1 A
DC output voltage	12
Power source type	DC
Power consumption (max)	6 W
Mounting type	Wall
Product color	Black, White
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Intelligent Video Surveillance (IVS) system features	Human detection
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Cloud services supported	EZVIZ Cloud
Maximum memory card size	256 GB
Frequency band	2.4 - 2.4835 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	20 MHz
Wi-Fi data rate (max)	72 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	EZVIZ Cloud Proprietary Protocol
Lens mount interface	M12
Pan range	0 - 352 °
Tilt angle range	0 - 95 °
Camera shutter type	Electronic
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \

Weight and Dimensions

Depth	158 mm
Width	149 mm
Height	157 mm
Weight	510 g
Package depth	197 mm
Package width	205 mm
Package height	185 mm
Package weight	885 g
