Ezviz CS-CV246 User Manual

5
Installation
1� Micro SD Card Installation (Optional)
1. Remove the cover on the camera.
2. Insert the micro SD card (sold separately) into the card slot.
3. Fix the cover to the camera.
Micro SD Card Slot
(Remove the cover)
After installing the micro SD card, you should initialize the card in the EZVIZ app
before using it.
4. In the EZVIZ app, tap the Storage Status in the Device Settings interface to
check the SD card status.
5. If the memory card status displays as Uninitialized, tap to initialize it.
The status will then change to Normal and then videos can be stored.
2� Installation Location
• Choosealocationwithaclear,unblockedeldofviewandwithagoodwireless
signal.
• Make sure the wall is strong enough to withstand three times the weight of the
camera.
• Camera cannot be installed with the lens facing direct sunlight.
3� Installation Procedure
The camera can be wall mounted and ceiling mounted.
Ceiling/Wall Mount
1.Removetheprotectivelmfromthelens.
2.Stickthedrillingtemplateontoacleanandatsurface.
3. (For cement wall only) Drill screw holes according to the template, and insert
anchors.
4.Usescrewstoxthecameraontheinstallationsurface.

Ezviz CS-CV246 Specifications

General

Resolution	1920 x 1080
Audio	Built-in microphone and speaker
Power Supply	DC 5V/1A
Image Sensor	1/2.7"Progressive Scan CMOS
Day & Night	IR-cut filter with auto-switching
DNR	3D DNR
Video Compression	H.264
Max. Resolution	1920 x 1080
Power Consumption	Max. 5W
Night Vision	Up to 10 meters
Connectivity	IEEE802.11 b/g/n
Storage	MicroSD card slot
Lens	4mm @ F2.2
Frame Rate	Up to 15 fps
Smart Alarm	Motion detection
Protocol	EZVIZ Cloud Proprietary
Interface Protocol	EZVIZ Cloud Proprietary
Operating Conditions	-10°C to 45°C, Humidity 95% or less (non-condensing)
Operating Temperature	-10°C to 45°C
Weight	256 g
