Ezviz Mini Plus User Manual

7
Installation
Step 1 Installing the Metal Plate (Optional)
Pick a clean and flat surface and secure the metal plate to the desired
position with the foam stickers or screws.
There’s a magnet piece inside the camera. You can skip this step if the
surface is made of metal.
Step 2 Installing the Camera
Secure the camera magnetically to the metal plate or metal surface.
Step 3 Completing Installation
Adjust the camera angle as required.
Recording on the Memory Card
Step 1 Installing the Memory Card
1. Flip the memory card slot cover clockwise to open it, see the following
left figure.
2. Insert a microSD card into the slot until a click, see the following right
figure.
3. Replace the cover.
Step 2 Initializing the Memory Card
1. From the EZVIZ app, check the memory card status by tapping on the
Storage Status in the Device Settings.
2. If the memory card status displays as Not Initialized, tap the Initialize
button to initialize it. You can then record event triggered video in the
camera after the initialization completed.

Ezviz Mini Plus Specifications

General

Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wireless
Infrared (IR) cut-off filter	Yes
Form factor	Box
Mounting type	Desk/Wall
Product color	White
Camera shutter speed	1/30 - 1/100000 s
Minimum illumination	0 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \
LED type	IR
Night vision distance	7.5 m
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Frequency band	2.4/5 GHz
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	150 Mbit/s
Number of cameras	1
Mobile operating systems supported	Android, iOS
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	5
Power source type	DC
Power consumption (max)	3.5 W
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Image quality adjustment	Brightness, Contrast, Saturation
Video compression formats	H.264
Supported graphics resolutions	1920 x 1080 (HD 1080)
Audio system	2-way
Fixed focal length	2.8 mm
Minimum aperture number	2
Lens mount interface	M12

Weight and Dimensions

Depth	29 mm
Width	52 mm
Height	85 mm
Weight	85.5 g
