Ezytrail Parkes Series User Manual

OWNER’S HANDBOOK
PARKES RANGE
All the info you need to know when using your
Ezytrail Parkes Hybrid Offroad Caravan
www.ezytrail.com.au
Read owner’s manual before using the equipment. Third party component
manuals should be read in conjunction with this manual. Maintenance
guidelines must be met or exceeded, failing to meet these guidelines may
result in serious injury or death and property damage.

Ezytrail Parkes Series Specifications

General

Category	Caravans
Manufacturer	Ezytrail
Series	Parkes Series
Brakes	12-inch electric brakes
Toilet	Yes

Summary

Introduction

Setting Up Your Caravan

Loading Your Caravan

Properly load your caravan to distribute weight evenly and achieve suitable ball weight load.

Choosing a Spot to Set Up

Select a flat camp spot away from overhanging trees and areas prone to flooding.

Levelling Your Caravan

Use jockey wheel and stabiliser legs for levelling. Avoid using stabilisers as lifting mechanism.

Site Power

Connect via 15A socket/outlet. Use appropriate leads and avoid coiling leads when in use.

Kitchen

Learn how to open, close, and support the kitchen for safe transit and use.

Preparing for Bad Weather

Close vents/hatches, secure awning, ensure good drainage, and close external doors.

Packing Down Your Caravan

Turn off appliances, secure loose items, lock doors/drawers, lower roof, and secure doorstep.

Storage and Care

Interior

Reduce moisture and avoid mould by drying thoroughly and using moisture absorbers.

Exterior

Protect seals and fittings from UV and elements using covers or tarpaulins.

Batteries

Ensure power is off, charge monthly, and avoid draining below 12.05V.

Securing Your Caravan

Use wheel chocks, wheel clamp, or hitch lock when parked and unhitched.

Torque Settings

Tighten wheel nuts to 125Nm, hitch bolts to 150Nm, and pivot bolts to 180Nm.

Brakes and Handbrake

Brake Controller

Adjustable controller for braking capability, variable force, and emergency braking.

Trailer Plug Wiring

Diagrams for correct wiring of flat and round 7-pin plugs for trailer lights and brakes.

Breakaway Switch

System to halt trailer if detached. Lanyard pulls pin, batteries activate brakes. Ensure charging.

Hand Brake

Mechanically operated parking brake. Adjust cable tension for proper engagement.

Adjuster

Adjust handbrake cable tension by turning the adjuster wheel clockwise.

Correct Use of Your Electric Brakes

Synchronise trailer brakes with tow vehicle. Maintain and adjust brakes as per controller manual.

Brake Adjustment

Adjust brakes after first 500km and at 10,000km intervals or as use requires.

Brake Cleaning and Inspection

Inspect and service trailer brakes at 10,000km. Check magnets and shoes for wear.

Magnets

Inspect and replace electromagnets if worn unevenly. Replace in pairs.

Shoes and Linings

Inspect brake linings for wear, contamination, or scoring. Replace in pairs.

Corrosion Prevention

Protect fittings from corrosion using sprays, especially near oceans or waterways.

Wheels and Tyres

Highway

Recommended tyre pressures: 36-70 psi depending on ATM. Check wheel nuts.

Off Road

Reduce tyre pressures by 30% for off-road. Adjust speed and pressure for conditions.

Electrical Systems

Chargers & Inverters

Refer to component manuals for detailed information on appliances.

Battery Care

Maintain 100Ah deep cycle batteries. Charge monthly, use quality charger, avoid low voltage.

Control Panel

Overview of control panel functions: USB, 12V sockets, gauges, meters, and switches.

Gas & Water Systems

Information on hot water systems and water pumps, including warnings.

Gas & Water Systems

Connecting the Gas

Connect gas bottle, ensure controls are off, turn on valve. Purge lines before use.

Protecting from Mould

Prevent mould by drying interior, airing caravan, and using moisture absorbers.

Pre-Trip Checklist

Useful Accessories

Levelling Blocks

Aid in levelling trailer on setup, support stabiliser legs, and improve stability.

Wheel Chocks

Safety device for parking on inclines. Chock wheels on downhill side.

Covers

Storage covers protect fittings from UV radiation, paint, and gelcoat finishes.

Stone Protection

Use devices like Rock Tamer or Stone Stomper to protect trailer from stones.

Trouble Shooting

Electrical

Troubleshoot common electrical problems like no power, charging, or lights not working.

Water

Troubleshoot water pump issues like no noise, no water flow, or kinked hoses.

Gas

Troubleshoot gas cooker ignition problems: empty bottle, regulator issues, or dirty stove.

Brakes

Troubleshoot brake issues: no brakes, weak brakes, locking brakes, or intermittent brakes.

Handy Tips

Driving Off Road

Carry spares, perform maintenance, adjust tyre pressure, and drive carefully on rough roads.

Bulldust

Reduce speed and drive carefully in bull dust to avoid damage or accidents.

Wildlife

Be aware of wildlife on outback roads, especially at dawn/dusk. Adjust speed for braking distance.

Sand

Lower tyre pressures for sand driving to increase footprint. Avoid sharp turns and maintain low speed.

Causeways

Reduce speed when approaching causeways to avoid danger to motorists and vehicles.

Creek and River Crossings

Exercise extreme caution at water crossings. Never attempt in flood conditions.

Protecting the Environment

Take precautions in remote areas and National Parks. Use grey water tanks and secure rubbish.

Trip Planning

Consider resupply points for fuel, food, and water for remote trips. Check conditions.

Shire Councils

Utilise shire council websites for local information on camping, activities, and bookings.

National Parks

Check national parks websites for campsites and specific information about park features.

Wikicamps

Smartphone app for finding camping spots, especially free camping, and fuel stops.

Facebook

Join Facebook groups for travel tips, local conditions, and research on specific areas.

Warranty Statement

Validity of Claims

Warranties are for original purchaser, new items only. Not transferable, no hire/rental use.

Caravans & Camper Trailers

12-month limited manufacturer's warranty. Consumer Law guarantees apply for major failures.

Items Not Covered Under Warranty Include

Excludes rust, tyres, paint, consumables, zips, and mesh. Consumer Law rights apply.

Tents

Tents guaranteed in merchantable condition. 12-month warranty on canvas, poles, fittings.

Lodging a Claim

All warranty claims must be lodged via the website using the online Warranty Claim Form.

Contact

Contact Ezytrail for warranty questions via phone or online help center.
