CHARACTERISTICS
Components
Ref. Q.ty Product Components
1 1 Hood Body, complete with: Controls, Light, Blower,
Filters
2.1 1 Upper Section (optional)
2.2 1 Lower Section (optional)
8 1 Directional Air Outlet grille
9 1 Flange (optional)
15 1 Angle iron (optional)
16 1 Filter cover
Ref. Q.ty Installation Components
7.2.1 2 Upper Chimney Section Fixing Brackets (optional)
11 6 Wall Plugs ( 4 optional )
11a 2 Wall Plugs SB 12/10
12a 6 Screws 4,2 x 44,4 ( 4 optional )
12c 10 Screws 2,9 x 6,5 ( 6 optional )
12d 6 Screws 2,9 x 9,5 ( 4 optional )
Q.ty Documentation
1 Instruction Manual
12d
2.1
2.2
12c
9
15
12a
7.2.1 11
1
12a
16
12c
12d
8
11
11a
