4.7 False Chimney breast
Construct the false chimney breast from non- combustible material in combination
with metal profiles or of brickwork / aerated concrete bricks.
Take the grills and the service panel (see fig. 1.1 an1.2 )into account. Place a
protective shield made of non- combustible material above the grills (see fig 1.1 A)
Always use a lintel if the chimney breast is constructed of brickwork. This should
not be placed directly onto the appliance
4.8 Frameless without optional decorative sheet
Construct the false chimney breast against the build-in frame (see fig. 1.1 B).
Keep a minimum margin of 3 mm between chimney breast and the appliance in
connection with the expansion of the appliance.
The depth of the recess has no influence on the removal of the glass.
4.9 Frameless with optional decorative sheet
Construct the false chimney breast around against the build-in frame (see fig. 1.1
B) apart from the lower half. Keep a minimum margin of 3 mm between chimney
breast and the appliance in connection with the expansion of the hearth.
The height of the lower half should correspond with the height of the groove(see fig
1.5 )
Place the decorative sheet on top the build-in frame.
5 removing the glass
5.1 removing the glass in front
Remove the cover strips A on the side. (see fig.2.1)
Remove cover strip B on the bottom. (see fig. 2.2 )
Place the suction discs onto the glass
Remove the sealing cord from the groove (see fig. 2.3 )
Slide the glass to the side and upwards so that the bottom edge is released from
the groove. Now gradually move the glass outwards and downwards. (see fig. 2.4 )
5.2 removing the glass on the side
It is not necessary to take out the glass on the side for placing the artificial logs or for
maintenance purposes.
